序号

零 件 代 号

版本

名 称

数量

适用车号

选装

No.

Part No.

Ver.

Part Name

Q’ty

Suit Num.

Cho

1

W-06-00148

1

蓄电池|115E41R Battery

2

9570001-

2

W-06-00061

1

闪光器|JSG252C Flash relay

1

9570001-

3

W-11-00104

1

电源开关|K01K18-A Knife switch

1

9570001-

4

W-06-00304

1

保险丝盒|HG-4735-8 Fuse box

1

9570001-

5

W-06-00307

1

保险丝|C-20A

Fuse 20A

6

9570001-

6

W-06-00306

1

保险丝|C-10A

Fuse 10A

2

9570001-

7

W-06-00268

1

保险丝盒|BX2022/50A Fuse

1

9570001-

8

W-06-00053

1

喇叭|DL229G

Horn

1

9570001-

9

W-05-00060

前组合大灯|HD200X110 Front lamp

2

9570001-

10

W-06-00314

1

ZJB2007-02

1

–

– –

–

–

12

W-06-00311

1

继电器|MZJ50A/006 Relay

1

9570001-

13

W-12-00143

1

自粘式吸盘|TM30 Acetabulu

9

9570001-

14

W-11-00047

1

转向灯开关|JK802A Steering lamp switch

1

9570001-

15

W-06-00069

1

收放机天线|YT3480 Antenna

1

9570001-

16

W-06-00068

1

收放机喇叭|4MB1 Speaker

2

9570001-

17

W-09-00069

1

后雨刷器|ZD2330C/Z50E-3 Rear wiper

1

9570001-

18

W-09-00104

1

洗涤器|XD205 Scrubbers

1

9570001-

19

W-06-00147

1

CD 机|YX-24 CD Machinery

1

9570001-

20

W-06-00047

1

继电器|JD2914J Relay

1

9570001-

21

W-06-00310

1

继电器|MZJ100A/006 Relay

1

9570001-

22

W-11-00010

1

开关|JK931

Switch

1

9570001-

23

W-05-00028

1

照灯|202

Working lamp

2

9570001-

24

W-05-00015

1

后组合灯|XHYJKJ24-101 Rear group lamp

2

9570001-

25

W-09-00037

1

雨刷器|MFD190 Wiper

1

9570001-

26

W-09-00001

1

风扇|756720C

Fan

1

9570001-

27

W-05-00009

1

工作灯|201 Working lamp

2

9570001-

28

W-05-00002

1

顶灯|NZ1-4

Tip lamp

1

9570001-

29

W-06-00034

1

二极管|1N4007 Transistor diode

2

9570001-

30

W-06-00163

1

蜂鸣器|GPS-86T20B-1M Buzzer

1

9570001-

– –

–

–

32

W-11-00070

1

开关组件|JK931/Z40H

·仪表灯开关

·前照灯开关

·后照灯开关

·工作灯开关

·风扇开关

·前雨刷器开关

·后雨刷器开关

Combine switch

Meter lamp switch

Front lamp switch

Rear lamp switch

Working lamp switch

Fan switch

Front wiper switch

Rear wiper switch

1

1

1

1

1

1

1

1

9570001-

9570001-

9570001-

9570001-

9570001-

9570001-

9570001-

9570001-

序号

No.

零 件 代 号

Part No.

版本

Ver.

名 称

Part Name

数量 Q’ty

适用车号

Suit Num.

选装

Cho

1

SD5H14

1

压缩机

compressor

1

9570001-

2

W-08-00040

1

空调器总成 BKG-08A Air-condition

1

9570001-

3

T0310206

1

低压软管 L=3200 tube

1

9570001-

4

T0310015

1

高压软管 L=3100 Tube

1

9570001-

5

B-Q020020-00004

1

箍 90

hoop

8

9570001-

6

T0520048

1

贮液器组件 oil storage

1

9570001-

7

B-G057830-00128

1

螺栓 M6X12ZnD

Bolt

2

9570001-

8

B-G000930-00015

1

垫圈 6

Washer

2

9570001-

9

B-G00097B-00021

1

垫圈 6ZnD

Washer

2

9570001-

10

T0100042

1

蒸发器

evaporator

1

9570001-

11

B-G057830-00030

1

螺栓 M12X25ZnD Washer

4

9570001-

12

B-G000930-00003

1

垫圈 12

Washer

4

9570001-

13

B-G00097B-00004

1

垫圈 12ZnD

condensator

4

9570001-

14

T0200001

1

冷凝器总成

冷凝器

1

9570001-

15

B-G057830-00010

1

螺栓 M10X30ZnD Washer

4

9570001-

16

B-G000930-00001

1

垫圈 10

Washer

7

9570001-

17

B-G00097B-00002

1

垫圈 10ZnD

condensator

5

9570001-

18

Z50E.21G-3

1

双头螺栓

Bolt

1

9570001-

19

B-G061700-00003

1

螺母 10ZnD

Nut

2

9570001-

20

Z50E.21D-1

1

压缩机支架

bracket

1

9570001-

21

Z50E.21D-2

1

调节螺杆

screw

1

9570001-

22

B-G057830-00076

1

螺栓 M16X45ZnD Washer

1

9570001-

23

B-G00097B-00008

1

垫圈 16ZnD

Washer

1

9570001-

24

B-G000930-00006

1

垫圈 16

condensator

1

9570001-

25

B-Q020490-00005

1

垫圈 14

condensator

2

9570001-

26

B-G061700-00010

1

螺母 14ZnD

Nut

2

9570001-

27

Z50E.21D-3

1

调节板

board

1

9570001-

28

B-G057830-00018

1

螺栓 M10X50ZnD Washer

1

9570001-

29

Z50E.21D-4

1

调整垫

Washer

2

9570001-

30

T0160005

1

风管φ50X500 pipeline

4

9570001-

31

B-J088700-00017

1

喉箍 d60

Clamp

22

9570001-

32

Z40E.21F-1

1

三通

tube

1

9570001-

33

T0160006

1

风管φ50X100 pipeline

1

9570001-

34

T0160007

1

风管φ50X750 pipeline

1

9570001-

35

T0160002

1

风管φ50X870 pipeline

2

9570001-

36

T0160009

1

风管φ50X650(外包海绵) pipeline

3

9570001-

37

Z30.16.4-16

1

出线圈 36

Outlet loop

4

9570001-

38

Z50E.21D-5

1

进水管 φ 16×2800 Hose

1

9570001-

39

T0310206

1

高压软管

tube

2

9570001-

40

Z50E.21D-6

1

出水管 φ 16×1800 Hose

1

9570001-

41

B-J088700-00012

1

喉箍 d25

Clamp

4

9570001-

42

1

V 带 A-1345

strap

1

9570001-
